TL725P-CAN2.0A/B IMU GYRO FOR FARM MACHINERY CAN2.0A/B OUTPUT OPTIONAL

Name: TL725PCAN20AB IMU GYRO FOR FARM MACHINERY CAN20AB OUTPUT OPTIONAL
Brand: RION
Price: 43 USD

Brand Name : RION

Model Number : TL725P-C2/C3

Certification : CE

Place of Origin : China

MOQ : 1

Price : 43

Payment Terms : paypal T/T

Supply Ability : 5000/month

Delivery Time : 5 days for samples

Packaging Details : carton box with sponge

Three-axis attitude : relative heading ±180°, Roll angle ±180°, Pitch angle ±90°

Bandwidth : >100Hz

Nonlinear : 0.1% of FS

Startup time : 250ms

Input voltage : +9~36V

Current : 35mA(12V)

Contact Now

TL725P-CAN2.0A/B IMU GYRO FOR FARM MACHINERY CAN2.0A/B OUTPUT OPTIONAL

▶ MAIN FEATURE

★ Horizontal relative heading and attitude angle output

★ Real-time angular rate output

★ Long life and strong stability

★ Forward axis acceleration

★ Compact and lightweight design

★ CAN2.0A/B output optional

★ All solid state

★ Light weight

★ DC9~36V power supply

▶ APPLICATION

★ Automated agricultural machinery

★ Precision agriculture

★ Combination Harvesters

★ Farming machine

● SPECIFICATIONS

TL725P-C2/C3		PARAMETERS
Three-axis attitude		relative heading ±180°, Roll angle ±180°, Pitch angle ±90°
Bandwidth		>100Hz
Nonlinear		0.1% of FS
Accelerometer	accelerometer range	± 2g, ± 4g, ± 8g, ± 16g can be set
	Acceleration resolution	0.001g
	Acceleration accuracy	1mg
	Bias instability (allan)	0.05mg
	Speed random walk coefficient (allan)	0.015m/s/sqrt(h)
	Zero bias stability (10s mean)	0.15mg
Gyro	Gyro Range	250 °/s, 500 °/s can be set
	Angular random walk coefficient (allan)	0.25°/sqrt(h)
	Zero bias stability (10s smooth)	8.5°/h
Startup time		250ms
Input voltage		+9~36V
Current		35mA(12V)
Working temp		-40 ~ +80℃
Storage temp		-40 ~ +85℃
Vibration		5g~10g
Impact		200g pk, 2ms, ½sine
Working life		10 years
Output frequency		1Hz~200Hz Settable
Output signal		CAN 2.0A / CAN2.0B(Optional)
MTBF		≥50000 Hours/times
Insulation resistance		≥100 MΩ
Shockproof		100g@11ms, 3 Axial Direction (Half Sinusoid)
Anti-vibration		10grms,10~1000Hz
Protection grade		IP67
Cable		Standard 1 m 4 pin shield wire
Weight		≤135g (including 1 meter standard cable)
